TL072 Operational Amplifier SOD-8

The TL072 Operational Amplifier SOD-8 is a high-performance, low-noise op-amp widely used in precision signal processing applications, including solar inverters. Designed with JFET-input technology, the TL072 operational amplifier offers high input impedance, low distortion, and superior frequency response, making it ideal for high-accuracy circuits. Its dual op-amp configuration provides exceptional performance in voltage amplification, active filtering, and signal conditioning. The TL072 op-amp SOD-8 package ensures compatibility with compact PCB designs, making it an excellent choice for space-constrained electronic projects.

Built for efficiency and reliability, the TL072 low-noise Amplifier plays a crucial role in minimizing interference in solar inverter control systems, ensuring stable and noise-free signal transmission. With its precision characteristics, the TL072 precision enhances power conversion efficiency and overall system stability. As an SMD operational amplifier, it is well-suited for modern, high-density circuit boards, providing durability and high-speed signal processing. Whether for solar energy applications, industrial control systems, or audio signal processing, the TL072 is a trusted solution for high-performance electronic designs.

Features

  • High slew rate: 20 V/μs (TL07xH, typ)
  • Low offset voltage: 1 mV (TL07xH, typ)
  • Low offset voltage drift: 2 μV/°C
  • Low power consumption: 940 μA/ch (TL07xH, typ)
  • Wide common-mode and differential voltage ranges – Common-mode input voltage range includes VCC+
  • Low input bias and offset currents
  • Low noise: Vn = 18 nV/√Hz (typ) at f = 1 kHz
  • Output short-circuit protection
  • Low total harmonic distortion: 0.003% (typ)
  • Wide supply voltage: ±2.25 V to ±20 V, 4.5 V to 40 V

Applications

  • Solar energy: string and central inverter
  • Motor drives: AC and servo drive control and power stage modules
  • Single phase online UPS
  • Three phase UPS
  • Pro audio mixers
  • Battery test equipment
