PC817 GENERAL PURPOSE PHOTOCOUPLER SOD-4

PC817 GENERAL PURPOSE PHOTOCOUPLER SOD4

The PC817 general-purpose photocoupler is a reliable SOD-4 photocoupler designed for high-efficiency signal isolation. This PC817 optocoupler ensures safe and efficient transmission of electrical signals while protecting circuits from high-voltage surges. Widely used in industrial and consumer electronics, it is an essential optocoupler for solar inverters, microcontrollers, and switching power supplies.

Engineered for durability, the PC817 photocoupler provides excellent electrical isolation, minimizing interference and enhancing circuit performance. Its PC817 datasheet highlights its low power consumption and high-speed response, making it ideal for power conversion and automation systems. This PC817 for solar inverter component supports smooth signal transmission, ensuring optimal inverter performance. Whether used in motor controls or renewable energy applications, this general-purpose photocoupler is a cost-effective and efficient solution.

PC 817X Series contains an IRED optically coupled to a phototransistor. It is packaged in a 4pin DIP, available in wide-lead spacing option and SMT gullwing lead-form option. Input-output isolation voltage(rms) is 5.0kV. Collector-emitter voltage is 80V(*) and CTR is 50% to 600% at input current of 5mA.

Features

1. 4pin SOD package
2. Double transfer mold package (Ideal for Flow Soldering)
3. High collector-emitter voltage (VCEO:80V(*))
4. Current transfer ratio (CTR : MIN. 50% at IF=5 mA, VCE=5V)
5. Several CTR ranks available
6. High isolation voltage between input and output (Viso(rms) : 5.0 kV)
