MC9S08FL16CLC IC FOR UPS AND SOLAR INVERTER LQFP 32 (0172)

MC9S08FL16CLC IC FOR UPS AND SOLAR INVERTER LQFP 32

The MC9S08FL16CLC microcontroller is a reliable and efficient solution for power management applications, including UPS systems and solar inverters. Designed to deliver stable performance, this 8-bit S08 MCU ensures precise control and seamless integration into embedded systems. With its optimized architecture, it supports smooth operation in demanding environments, making it a preferred choice for energy-efficient solutions. The LQFP-32 package IC allows for compact circuit designs while maintaining high functionality.

Engineered for durability and precision, the 16KB flash memory IC provides ample storage for control algorithms and real-time data processing. This UPS controller IC is widely used in power backup systems, enhancing efficiency and reliability. As a solar inverter microcontroller, it plays a key role in optimizing power conversion and system stability. The NXP MC9S08FL16CLC is trusted by engineers for its versatility in embedded applications. Whether for renewable energy systems or power electronics, this embedded control IC ensures superior performance and long-term reliability.

Features:

8-Bit S08 Central Processor Unit (CPU)

• Up to 20 MHz CPU at 4.5 V to 5.5 V across temperature range of –40 °C to 85 °C
• HC08 instruction set with added BGND instruction
• Support for up to 32 interrupt/reset sources

On-Chip Memory

• Up to 16 KB flash read/program/erase over full operating voltage and temperature
• Up to 1024-byte random-access memory (RAM)
• Security circuitry to prevent unauthorized access to RAM and flash contents

Power-Saving Modes

• Two low power stop modes; reduced power wait mode
• Allows clocks to remain enabled to specific peripherals in stop3 mode

Clock Source Options

• Oscillator (XOSC) — Loop-control Pierce oscillator; crystal or ceramic resonator range of 31.25 kHz to 39.0625 kHz or 1 MHz to 16 MHz
• Internal Clock Source (ICS) — Internal clock source module containing a frequency-locked-loop (FLL) controlled by internal or external reference; precision trimming of internal reference allows 0.2% resolution and 2% deviation over temperature and voltage; supports bus frequencies up to 10 MHz

System Protection

• Watchdog computer operating properly (COP) reset with option to run from dedicated 1 kHz internal clock source or bus clock
• Low-voltage detectionwith reset or interrupt; selectable trip points
• Illegal opcode detection with reset
