DB107 1000V 1A SMD BRIDGE RECTIFIER SOP-4

DB107 1000V 1A SMD BRIDGE RECTIFIER SOP-4

The DB107 is a compact and efficient 1000V bridge rectifier designed for AC to DC conversion in solar inverter and power supply applications. This 1A bridge rectifier ensures stable operation with low forward voltage drop, minimizing power loss. As an SMD bridge rectifier, it features a SOP-4 bridge rectifier package for easy surface-mount integration in compact circuits.

Optimized for high efficiency, the DB107 for solar inverter provides excellent performance in high-voltage applications. Its SOP-4 bridge rectifier design ensures thermal stability and high surge current capability, making it ideal for renewable energy systems. With a 1000V bridge rectifier rating and 1A current capacity, it offers reliable protection against voltage fluctuations. The DB107 datasheet highlights its superior design, making it a top choice for SMD bridge rectifier applications in industrial and solar power management systems.

This Bridge Rectifier is a compact SMD component designed for solar inverters, chargers, and power circuits. It converts AC to DC efficiently, handling up to 1000V voltage and 1A current. With its SOP-4 package, it is easy to mount on circuit boards, making it ideal for solar power systems, LED drivers, and battery chargers. High durability ensures stable performance in various electronic applications.

Specifications:

• Peak Repetitive Reverse Voltage: 700V
• Maximum RMS Reverse Voltage: 420V
• Average Rectified Output Current: 1A
• Non-Repetitive Peak Forward Surge Current: 35A
• Forward Voltage Drop: 1V
• Peak Reverse Current: 10uA
• Maximum Working Temperature: +150C
