SG 3525 PWM CONTROLLER IC LARGE SOIC-16L

SG 3525 PWM CONTROLLER IC LARGE SOIC-16L

The SG3525 PWM Controller IC is a high-performance power management solution designed for precision control in solar inverter repairing and other power electronics applications. This SG 3525 IC is widely used for switch-mode power supplies, DC-DC converters, and inverter circuits due to its stable operation and efficient pulse width modulation (PWM) control. Its SG3525 SOIC-16L package offers a compact design with robust electrical performance, ensuring smooth energy conversion and optimized voltage regulation. Whether you’re designing or repairing inverters, this PWM controller IC provides precise output regulation, making it a reliable choice for engineers and technicians.

Equipped with an advanced SG3525 voltage regulator, this controller offers excellent frequency stability, built-in short-circuit protection, and improved energy efficiency. Backed by the SG3525 datasheet, it provides accurate signal processing and enhanced reliability for demanding applications. If you need a high-performance PWM controller to optimize your solar inverter systems or other power supply circuits, this IC is an excellent solution.

The series of pulse width modulator integrated circuits are designed to offer improved performance and lowered external parts count when used in designing all types of switching power supplies. The on-chip + 5.1 V reference is trimmed to ± 1 % and the input common-mode range of the error amplifier includes the reference voltage eliminating external resistors. A sync input to the oscillator allows multiple units to be slaved or a single unit to be synchronized to an external system clock. A single resistor between the CT and the discharge terminals provide a wide range of dead time adjustment. These devices also feature built-in soft-start circuitry with only an external timing capacitor required. A shutdown terminal controls both the soft-start circuitry and the output stages, providing instantaneous.
