LM7912 NEGATIVE VOLTAGE REGULATOR TO-220

LM7912CV SERIES 3-TERMINAL NEGATIVE VOLTAGE REGULATOR

The LM7912CV voltage regulator is a high-performance 12V negative voltage regulator designed to deliver a stable and reliable -12V output, making it an essential component for solar inverters and other power management systems. As a LM7912CV 3-terminal regulator, it efficiently regulates voltage, protecting sensitive electronics from power fluctuations and ensuring consistent operation. With built-in thermal overload protection, short-circuit protection, and safe operating area compensation, this LM7912CV negative voltage regulator offers superior reliability, making it ideal for applications requiring precise voltage control.

Encased in a LM7912CV TO-220 package, this regulator provides excellent thermal dissipation, allowing it to handle higher power loads efficiently. For compact designs, the LM7912CV SMD variant offers flexibility in PCB layouts, making it suitable for modern electronic circuits. Whether used in renewable energy systems, industrial automation, or regulated power supplies, this regulator ensures optimal performance. For detailed specifications and electrical characteristics, users can refer to the LM7912CV datasheet, which provides essential information for integration into various electronic projects.

This is a negative voltage regulator that provides a steady -12V output. It is commonly used in solar inverters to keep the voltage stable and protect sensitive electronic parts. This regulator has three terminals – input, ground, and output. It helps in converting higher DC voltage into a safe and fixed -12V, preventing damage to the system. It also has built-in protection against overheating and short circuits, making it reliable for long-term use in solar power systems.

Features:

• Output current in excess of 1.5A
• Output voltage of -12V
• internal thermal overload protection
• Output transition Safe-Area compensation
• Minimum Lot-to-Lot variations for robust device performance and reliable operation
• Output voltage of -12V
• internal thermal overload protection
• Output transition Safe-Area compensation
• Minimum Lot-to-Lot variations for robust device performance and reliable operation
